A. Product Range | ||
Product Type | Thickness | Width |
1) Twin-walls polycarbonate sheet | 4-12mm | 2100mm/Customized |
2) Triple-walls polycarbonate sheet | 8-16mm | 2100mm/Customized |
3) Four-walls polycarbonate sheet | 8-20mm | 2100mm/Customized |
4) Honeycomb polycarbonate sheet | 6-11mm | 2100mm/Customized |
5) 5 layer honeycomb polycarbonate sheet | 14-25mm | 2100mm/Customized |
6) X-structure polycarbonate sheet | 14-30mm | 2100mm/Customized |
7) Solid polycarbonate sheet | 0.9-8mm | 1220mm/1560mm/1820mm/2100mm |
8) Corrugated polycarbonate sheet | 0.8-2.5mm | Customized |
9) Locking-design polycarbonate sheet | 3-10mm | 1040mm/Customized |
B. Length | ||
Customized (Recommend 5800, 6000, 11800, 12000mm to suit 20'container &40'container). | ||
C. Color | ||
Clear/Transparent, Lake Blue, Green, Blue, Opal, White, Brown/Bronze,Silvery Gray, Red, Yellow, etc. |
Polycarbonate X-structure wall sheet Product Standard & Technical Parameters | |||||
Thickness(mm) | Weight(kg/m2) | Minimum bending radius(mm) | Minimum span | Transparency(%) | Sound insulation(db) |
14 | 2.4 | 1400 | 2700 | 81 | 18 |
16 | 2.6 | 1750 | 3300 | 79 | 19 |
18 | 2.8 | 2100 | 3600 | 76 | 20 |
20 | 3 | ||||
25 | 3.5 | ||||
30 | 4 | ||||
Technical Parameters | |||||
Impact strength | Transparency | Specific grevity | Coefficient of thermal expansion | Service temperature | Heat conductivity |
2.1j/m-2.3j/m | 40%-80% | 1.2g/cm³ | 0.065mm/m°C | -40°C—120°C | 3.0-3.9w/m²°C |
Tensile strength | Flexural strength | Modulus of elasticity | Effect of sound insulation | Tensile stress at break | Elongation at break |
≥60N/mm | 100N/mm² | 2400Mpa | 10mm two laminates reduced 10db | ≥65Mpa | >100% |
1. Light transmission:12%-87% for different colors.
2. Ultraviolet-proof and aging-resistant: The product surface contains
anti UV co-extrusion layer,high outdoor weather resistance,can still maintain good optical characteristics and mechanical property after long-term use.
3. Shock resistance:High toughness,difficult to damage in transportation, installation and use.The impact strength is 10-27 times that of organic glass.
4. Heat preservation:Special hollow structure,can effectively reduce the energy consumption of building temperature regulation.
5. Sound insulation:Hollow structure and polycarbonate's excellent sound insulation property can reduce noise effectively.
6. Nonflammable:Reach the GB8624-2006 B-s1,d0,t0 certification level.
1) Impact strength: | 850J/m. About 200-350 times of common glass. |
2) Light weight: | About 1/2 times of glass of the same thickness. |
3) Light transmission: | 80%-92% for different thickness of clear color. |
4) Specific gravity: | 1.2 g/cm3 |
5) Coefficient of thermal expansion: | 0.065 mm/m° C |
6) Temperature range: | -30° C to 120° C |
7) Heat conductivity: | 2.3-3.9 W/m2 |
8) Tensile strength: | >=60N/mm2 |
9) Flexural strength: | 100N/mm2 |
10) Heat deflection temperature: | 140 ° C |
11) Modulus of elasticity: | 2, 400mPa |
12) Tensile street at break: | >=65mPa |
13) Elongation at break: | >100% |
14) Specific heat: | 1.16J/kgk |
15) Soundproof index: | 4mm-27dB,10mm-33dB |
·Industrial workshop, warehouse lighting roof
·Stadium lighting roof
·Swimming pool, greenhouse
·Residential and commercial lighting velarium
·Lighting materials of steel structure workshop
·Channel, parking shed
·Indoor partition
